CNC Single Column Vertical Turret Lathes VLK518E

微信截图_20220522213231
微信截图_20220522213241
description1
NameValueMax. turning diameter Vertical head (mm)1250Max. turning diameter Side head (mm)1100Max. workpiece height (mm)1200Max. workpiece weight (kg)4000Table diameter (mm)1000Speed range of table (r/
PRODUCT OVERVIEW

Name

Value

Max. turning diameter Vertical head (mm)

1250

Max. turning diameter Side head (mm)

1100

Max. workpiece height (mm)

1200

Max. workpiece weight (kg)

4000

Table diameter (mm)

1000

Speed range of table (r/min)

6.3~200

Speed-step of table

16

Max. torque of table (KN·m)

17.5

Max. cutting resistance of vertical head (KN)

20

Max. cutting resistance of side head (KN)

20

Total cutting resistance (KN)

35

Travel of vertical head (Horizontal) (mm)

700

Travel of vertical head (Vertical) (mm)


650 (5-position turret)
800(1 position ram)


Travel of side head (Horizontal) (mm)

500

Travel of side head (Vertical) (mm)

900

Travel of crossbeam (mm)

650

Feed range of vertical head and side head (mm/min)

0.8~86, 12 steps

Rapid moving speed of vertical head and side head (mm/min)

1800

Moving degrees limit of vertical head (°)

±30

Cutting section of tool bar (W×H) (mm)

30×40

Moving speed of crossbeam (mm/min)

660

Power of feeding motor (kW)

1.3/1.8

Power of main motor (kW)

22

Overall dimensions (L×W×H)

2460×2330×3430

Weight of machine (kg)

8500

Power supply

380V/50HZ/3PH

Position indication for railhead travel

2 axis DRO from SINO

PLC controller

Omron PLC

Electric components

Schneider electrics

CONFIGURATION

NO

Name

specification

Quantity

1

Chuck jaws


4

2

foot screw

M24X500

7

3

hexagonal nut

M24

7

4

Gasket

M24

7

5

Hexagonal wrench

S=36


6

internal hexagonal wrench

S=6.8.10.12.14


7

Square socket spanner

S=20

1

8

Square socket spanner

S=24

1

9

Tool holder


1

10

Boring bar


1

11

Taper hole cutter bar


1

12

Leveling base


8

13

Oil gun

200cm3

1

14

Sealing ring

40X3.5

2

Sealing ring

50

1

Sealing ring

B-50

1

Sealing ring

C-50

1

15

secondary filter net

100μm

2

16

triangular belt

C2240

6

17

Oil absorption net

100μm

1

18

Box spanner

32-36

1

19

Money spanner

250

1

20

Working lamp


1

21

DRO manual


1

22

Machine manual


1

23

Accuracy test


1

24

Packing list


1

MACHINE LIST

Universal Single-column Vertical Lathe Machine:

Specifications

Unit

VL518

VL5110

VL5112

VL51120

VL5126

VL5132

Max. turning diameter of railhead

mm

800

1000

1250

2000

2300

3200

Max. working height

mm

800

800

1000

1200

1500

1600

Max. weight of workpiece

T

1.2

2

4

8

10

10月30日

Table diameter

mm

720

900

1000

1800

2300

2830

Speed range of table

r/min

10~315

8~250

6.3~200

4~125

1.2~40

2~63

Speed-step of table

steps

16

16

16

16

16

16

Power of main motor

kW

15

22

22

30

37

37

Universal double column vertical lathe machine:

Specifications

Unit

VL5225

VL5232

VL5240

VL5250

VL5263

VL5280

VL52100

VL52125

Max. turning diameter

mm

2500

3150

4000

5000

6300

8000

10000

12500

Max. working height of workpiece

mm

1600

2000

1600

2000

3000

4000

4000

4000

Max. weight of workpiece

T

10

10/30

10/32

30/50

50

100

100

100

Table diameter

mm

2250

2830

2830/3200

3600/4500

3800

5700/6000

7100

7500

Speed range of table

r/min

2~63

2~63

2~63

0.2~40

0.5~50

0.2~20

0.16~16

0.16~16

Speed-step of table

steps

16

16

16

16

16

16

16

16

Travel of right tool post (Vertical)

mm

1300~1500

1000~1500

1000~1500

1250~1600

1600~2000

2000

2520

2520

Travel of left tool post (Horizontal)

mm

1400

1735

2150

20~2630

3415

50~4400

50~4400

50~4400

Power of main motor

kW

55

55

55/75

75/75

75

DC132

DC132

DC132

Free Std Accessories

S.N

Name

Remark

1

4-jaw chuck

1 set

6

Operation tools

1 set

8

Certificate of Conformity

1 set

9

Packing List

1 set

10

Instruction Manuals

1 set


PACKAGE
With fumigate wooden cases. Vacuum treatment is provided. Containers needed for the machine transportation: 1*40GP(separate package)or 1*20F/R(whole package)
