PRODUCT OVERVIEW
The symmetrical front-rear column structure design minimizes deflection and is most suitable for precision progressive die applications.

Noinher entangular deflection , which significantly extends die l i fe and reduces cost of tooling maintenance.

High rigidity structure ensures consistent dynamic precision.

High torque, enclosed wet clutch brake unit requires minimal maintenance, eliminates noise and pollution caused by a i rborne particles, and significantly extends lining life.

User-friendly multifunctional control system.

Designed to allow simple integrationwith automated auxiliary equipments.
PARAMETER

Model

11374

11375

11376

11377

11378

APE-160

APE-200

APE-250

APE-300

APE-400

S

H

S

H

S

H

S

H

S

H

Capacity

Ton

160

200

250

300

400

Rated tonnage piont

mm

6

3

6

3

7

3

7

3

7

Stroke

mm

180

130

250

150

280

170

300

170

300

Stroke per minute

s.p.m

30-55

40-85

20-50

35-70

20-40

30-60

20-35

30-50

20-30

Die height

mm

450

400

500

450

550

450

450

450

550

Slide adjustment

mm

100

120

120

120

120

Slide area

mm

1600x650

1850x750

2100x900

2200x900

3100x1000

Bolster area

mm

1800x760

2200x940

2500x1000

2500x1000

3200x1000

Side opening

mm

700x450

900x600

900x600

900x600

900x600

Main motor

kw

15

18

22

30

30

Slide adjust device

kw/xp

0.75x4

0.75x4

1.5x4

1.5x4

1.5x4

Air pressure

kg/cm2

5

5

5

5

5

Presses precision


GB(JIS)1 class

GB(JIS)1 class

GB(JIS)1 class

GB(JIS)1 class

GB(JIS)1 class
